| Lugar de origem: | China |
| Marca: | Shuowei |
| Certificação: | CE SGS ISO9001 |
| Número do modelo: | Série de R |
| Quantidade de ordem mínima: | 1PCS |
|---|---|
| Preço: | Negotiable |
| Detalhes da embalagem: | Caso de madeira; A embalagem personalizada é aceitável |
| Tempo de entrega: | 5-8 dias do trabalho |
| Termos de pagamento: | L/C, T/T |
| Habilidade da fonte: | 100 partes pelo mês |
| Apoio personalizado: | OEM, ODM, OBM | Torque da saída: | 85-18000NM |
|---|---|---|---|
| Velocidade da saída: | 0.5-280RPM | Velocidade entrada: | 650-3360RPM |
| Material do alojamento: | Ferro fundido HT250 | Formato entrado: | A flange do IEC, dirige com motor, entrada do eixo |
| Realçar: | Pinwheel Vertical Gear Reducer,650 rpm Vertical Gear Reducer,Vertical cycloidal pinwheel reducer |
||
Harmonic For Electric China Cyclo Drive Pinwheel Gearbox Cycloidal Pin Speed Planetary Motor Gear Reducer
2. The single stage transmission can achieve the reduction ratio of 1:87 and the efficiency is above%90. If multistage transmission is adopted, the deceleration ratio will be greater.
3. Compact structure, small volume
Because of the principle of planetary transmission, the input shaft and the output shaft are on the same axis, so the structure is compact and the volume is small.
4. Low running noise and low noise
The mechanism of cycloidal needle tooth engagement is large, the overlap coefficient is large, and the mechanism is stable.
Vertical Gear Reducer Main Features
Vertical Gear Reducer Parameters:
|
item
|
value
|
|
Warranty
|
12months
|
|
Applicable Industries
|
Manufacturing Plant, Machinery Repair Shops, Farms, Printing Shops, Energy & Mining, Food & Beverage Shops, Other
|
|
Customized support
|
OEM, ODM, OBM
|
|
Gearing Arrangement
|
Gear drive
|
|
Output Torque
|
1.6NM~5235NM
|
|
Input Speed
|
1450RPM
|
|
Output Speed
|
7.25RPM~290RPM
|
|
Place of Origin
|
China
|
|
Product name
|
Electric Motor Speed Reducer
|
Vertical Gear Reducer Advantages:
1. Large reduction ratio, 1-stage ratio 9~87, 2-stage ratio 121~1849, larger reduction ratio is available by 3-stage or multistage combinations
2. High efficiency, the average efficiency is over 90%
3. Compact structure, light weight
4. Stable and reliable operation, low noise
5. Long service life
Vertical Gear Reducer Reducer applied for
- Belt conveyor drives
- Bucket elevator drives
- Agitator drives
- Hoisting gear drives
- Travelling gear drives
- Paper machine drives
- Dryer drives
- Water screw drives
1. More than 35 years experience in R&D and manufacturing, export gear motors & industrial gearboxes.
2. Standardization of the gearbox series
3. Strong design capability for large power & customized gearboxes.
4. High-quality gearboxes and proven solutions provider.
5. Strict quality control process, stable quality.
6. Less than 2% of the quality complaints.
7. Modular design, short delivery time.
8. Quick response & professional services.
FAQ:
Q1. How can I choose the model that best meets my requirements?
A1. You can refer to our catalog to choose the gearbox or we can help to choose when you provide the technical information of required output torque, output speed and motor parameters, etc.
Q2. What information shall we give before placing a purchase order?
A2. a) Type of the gearbox, ratio, input and output type, input flange, mounting position, and motor detail, etc.
b) Housing color.
c) Purchase quantity.
d) Other special requirements.
Q3. What industries are your gearboxes being used in?
A3. Our gearboxes are widely used in automatic machinery and equipment in textile, food processing, beverage, chemical industry, escalator, automatic storage equipment, metallurgy, tobacco, environmental protection, logistics and other fields.
